ENGLISHKS-ZW202-Automatic Multi-bits Double head Drilling Machine
It adopts Italian mature design concept and application of the latest operation requirements and practice, mainly used for multi holes processing at two ends of Aluminum Alloyed materials and PVC materials simultaneously; It can punch Max. Eight holes simultaneously with single action, thus ensures the precision of multi holes at two ends and improves efficiency effectively.
TECHNICAL PARAMETER
|
Model and parameters |
KS-ZW202 Automatic Multi-bits Double head Drilling Machine |
|
Processing width |
400~2000mm |
|
Maximum diameter of drilling hole |
φ3-φ11 |
|
The distance of two apertures |
20-420mm |
|
Motor power |
2.2Kw X 2 |
|
Rotating speed of Motor |
2800rpm |
|
Working air pressure |
0.6-0.8Mpa |
|
Working voltage |
380VAC/50HZ |
|
Overall Dimension (L*W*H) |
3650×800×1220 mm |
|
Weight of machine |
1050kg |
